Power Cord IllustrationCord Set RatingPower Cord Part NumberLocale

16 A, 250 VACCAB-AC-16A-SG-INInternational/UK

16 A, 250 VACCAB-AC-16A-SG-ITItaly

16 A, 250 VACCAB-AC-16A-SG-SASouth Africa

Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide

122

System Specifications
