• Power mode to use and the number of extra power supplies required for that mode.
Ensure that the circuit that is used for the switch is dedicated to the switch to minimize the possibility of circuit
failure.
Calculate the power that is required for operations (available power) and redundancy (reserve power), then
you can plan for the required number of input power receptacles. The power receptacles will be within reach
of the switch location.
Step 1 Determine the power requirement for the modules in the switch by summing the maximum wattage for each installed
module, see the following table.
MaximumTypicalComponent
——Supervisor modules
90 W69 WSupervisor A (N9K-SUP-A)–
90 W69 WSupervisor A+ (N9K-SUP-A+)–
90 W75 WSupervisor B (N9K-SUP-B) (required for -R line cards)–
90 W75 WSupervisor B+ (N9K-SUP-B+) (required for -R and -R2 line cards)–
——System Controller modules
25 W14 WSystem Controller (N9K-SC-A)–
251 W176 WLine cards that are supported by N9K-C9508-FM fabric modules
432 W310 W8-port 100-Gigabit Ethernet CFP2 line card (N9K-X9408PC-CFP2)–
300 W240 W32-port 40-Gigabit Ethernet QSFP+ line card (N9K-X9432PQ)–
400 W360 W36-port 40-Gigabit Ethernet QSFP+ line card (N9K-X9536PQ)–
400 W260 W36-port 40-Gigabit Ethernet QSFP+ line card (N9K-X9636PQ)–
400 W300 W48-port 1/10-Gigabit Ethernet SFP+ and 4-port 40-Gigabit Ethernet QSFP+
line card (N9K-X9564PX)
–
240 W160 W48-port 1/10-Gigabit Ethernet SFP+ and 4-port 40-Gigabit Ethernet QSFP+
line card (N9K-X9464PX)
–
540 W450 W48-port 1/10GBASE-T and 4-port 40-Gigabit Ethernet QSFP+ line card
(N9K-X9564TX)
–
360 W300 W48-port 1/10GBASE-T and 4-port 40-Gigabit Ethernet QSFP+ line card
(N9K-X9464TX)
–
360 W288 W48-port 1/10GBASE-T and 4-port 40-Gigabit Ethernet QSFP+ line card
(N9K-X9464TX2)
–
570 W
420 W
455 W
266 W
Line cards that are supported by N9K-C9508-E and
N9K-C9508-E2 fabric modules
Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide
12
Preparing the Site
Planning for Power Requirements
