MaximumTypicalComponent
516 W415 W48-port 1/10/25-Gigabit Ethernet SFP28 and 4-port 40/100-Gigabit Ethernet
QSFP28 line card (N9K-X97160YC-EX)
–
684 W346 W48-port 1/100 BASE-T and 4-port 100-Gigabit Ethernet QSFP28 line card
(N9K-X9788TC-FX)
–
792 W632 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9736C-EX)–
900 W607 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9736C-FX)–
684 W571 W36-port 40-Gigabit Ethernet QSFP28 line card (N9K-X9736Q-FX)–
720 W430 W32-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9732C-EX)–
840 W520 W32-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9732C-FX)–
936 W685 WLine cards that are supported by N9K-C9508-FM-G fabric module
516 W415 W48-port 1/10/25-Gigabit Ethernet SFP28 and 4-port 40/100-Gigabit Ethernet
QSFP28 line card (N9K-X97160YC-EX)
–
684 W346 W48-port 1/100 BASE-T and 4-port 100-Gigabit Ethernet QSFP28 line card
(N9K-X9788TC-FX)
–
1680 W650 W16-port 400-Gigabit Ethernet QSFP-DD line card (N9K-X9716D-GX)–
900 W607 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9736C-FX)–
250 W240 WLine cards that are supported by N9K-C9508-FM-R fabric modules
1100 W800 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9636C-RX) with
TCAM
–
902 W650 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9636C-R)–
456 W329 W36-port 40-Gigabit Ethernet QSFP28 line card (N9K-X9636Q-R)–
300 W213 W16-port 1/10-Gigabit SFP, 32-port 10/25-Gigabit Ethernet SFP, and 4-port
40/100-Gigabit Ethernet QSFP line card (N9K-X96136YC-R
–
320 W280 WLine cards that are supported by N9K-C9508-FM-R2 fabric modules
1080 W900 W24-port 400-Gigabit Ethernet QSFP-DD line card (N9K-X9624D-R2)–
1100 W800 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9636C-RX) with
TCAM
–
902 W650 W36-port 100-Gigabit Ethernet QSFP28 line card (N9K-X9636C-R)–
456 W329 W36-port 40-Gigabit Ethernet QSFP28 line card (N9K-X9636Q-R)–
300 W213 W16-port 1/10-Gigabit SFP, 32-port 10/25-Gigabit Ethernet SFP, and 4-port
40/100-Gigabit Ethernet QSFP line card (N9K-X96136YC-R
–
400 W340 WLine cards that are supported by N9K-C9508-FM-S fabric modules
Cisco Nexus 9508 NX-OS Mode Switch Hardware Installation Guide
13
Preparing the Site
Planning for Power Requirements
