Step 3 Connect the office ground to the ONS 15454 M6 shelf. For detailed instructions on grounding, see the
Electrostatic Discharge and Grounding Guide for Cisco CPT and Cisco ONS Platforms.
Step 4 Complete the DLP-G575 Turn On and Verify DC Office Power on the ONS 15454 M6 Shelf, on page 116
Step 5 Continue with the NTP-G257 Install the Fan-Tray Assembly in the ONS 15454 M6 Shelf, on page 118.
Stop. You have completed this procedure.
DLP-G571 Connect Office Power (AC) to the ONS 15454 M6 Shelf
This task connects AC power to the ONS 15454 M6 shelf.Purpose
• #2 Phillips Dynamometric screwdriver
• Medium slot-head screwdriver
• Small slot-head screwdriver
• Wire wrapper
• Wire cutters
• Wire strippers
• Crimp tool
• Fuse panel
• Ground cable 13.3-mm² (#6 AWG) stranded. The PIDs of the power cables
are listed in Table 2: PIDs for AC Power Cables, on page 106.
Tools/Equipment
• NTP-G252 Install the ONS 15454 M6 Shelf , on page 24.
• NTP-G259 Open and Remove the Standard Door of the ONS 15454 M6
Shelf , on page 57.
• Connect the chassis to the office ground. For detailed instructions on how
to ground the chassis, see the Electrostatic Discharge and Grounding Guide
for Cisco CPT and Cisco ONS Platforms.
• NTP-G524 Install the Power Modules in the ONS 15454 M6 Shelf , on page
85.
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
This product is intended for use on the TN and TT power systems.
Note
When installing or replacing the unit, the ground connection must always be made first and disconnected
last. Statement 1046
Warning
Installing the ONS 15454 M6 Shelf
103
Installing the ONS 15454 M6 Shelf
DLP-G571 Connect Office Power (AC) to the ONS 15454 M6 Shelf
