• DLP-G561 Mounting the Bracket with Air Deflectors (Front-to-Back) on the ONS 15454 M6 Shelf for
ANSI Rack Configuration, on page 32
• DLP-G562 Mounting the Brackets on the ONS 15454 M6 Shelf for ETSI Rack Configuration, on page
34
• DLP-G563 Mounting the Air Deflectors (Front-to-Front) on the ONS 15454 M6 Shelf for ETSI Rack
Configuration, on page 36
• DLP-G564 Mounting the Bracket with Air Deflectors (Front-to-Back) on the ONS 15454 M6 Shelf for
ETSI Rack Configuration, on page 37
• DLP-G565 Mounting the Bracket with Air Deflectors (Front-to-Top) on the ONS 15454 M6 Shelf for
ETSI Rack Configuration, on page 39
• DLP-G821 Mounting the Bracket with Air Deflectors (Front-to-Side) on the ONS 15454 M6 Shelf for
ETSI Rack Configuration, on page 43
Step 3 Complete the necessary rack mounting task as applicable:
• DLP-G566 Mount the ONS 15454 M6 Shelf on a Rack (One Person) , on page 45.
• DLP-G567 Mount the ONS 15454 M6 Shelf on a Rack (Two People) , on page 47.
• DLP-G568 Mount Multiple ONS 15454 M6 Shelves on a Rack , on page 48.
Step 4 Connect the chassis to the office ground. For detailed instructions on how to ground the chassis, see the
Electrostatic Discharge and Grounding Guide for Cisco CPT and Cisco ONS Platforms .
Step 5 Continue with NTP-G259 Open and Remove the Standard Door of the ONS 15454 M6 Shelf , on page 57.
Stop. You have completed this procedure.
DLP-G674 Verify the ONS 15454 M6 Shelf for AC Power Module Installation
This task verifies the shelf for AC power module installation.Purpose
NoneTools/Equipment
NTP-G305 Unpack and Inspect the ONS 15454, ONS 15454 M2, and ONS 15454
M6 Shelves
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
Step 1 Verify the position of the mechanical locking system on the rear side of the chassis. To use the AC power
module, the screw must be close to the AC silk-screen text (see the following figure).
