• To configure the Catalyst 3560 using IOS commands for the ONS 15454 shelf as the node controller,
complete the NTP-G298 Configure a Cisco Catalyst 2950 or Catalyst 3560 (Active and Standby) for a
ONS 15454 Multishelf Node.
• To configure the Catalyst 3560 using IOS commands for the ONS 15454 M6 shelf as the node controller,
complete the NTP-G298 Configure a Cisco Catalyst 2950 or Catalyst 3560 (Active and Standby) for a
ONS 15454 Multishelf Node.
Stop. You have completed this procedure.
DLP-G682 Connect the ONS 15454 M6 as the Node Controller in a Mixed
Multishelf Configuration Using the Catalyst 3560
Use this procedure to connect the ONS 15454 M6 as the node controller and a
mix of ONS 15454 and ONS 15454 M6 as subtending shelves using a Catalyst
3560.
Purpose
• Two Cisco Catalyst 3560 switches must be installed in same rack as the node
controller shelf; see the Cisco Catalyst 3560 product documentation for
installation instructions.
• Cross-over (CAT-5) LAN cables (3, plus 2 for each subtending shelf)
Tools/Equipment
NTP-G15 Install the Common Control Cards.
NTP-G313 Install and Configure the TNC, TNCE, TSC, or TSCE Card
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
The MSM (multishelf management) ports are present on the ECU module. The MSM ports located on the left
side of the ECU module correspond to the TNC/TNCE/TSC/TSCE card in Slot 1, and the MSM ports located
on the right side correspond to the TNC/TNCE/TSC/TSCE card in Slot 8. For more information about the
ECU module and MSM ports, see the External Connection Units, on page 72.
Note
Use the craft terminal port or the EMS port present on the ECU module to connect the ONS 15454 M6 node
controller to the LAN.
Note
Procedure
Step 1 Using a cross-over (CAT-5) LAN cable:
Installing the ONS 15454 M6 Shelf
140
Installing the ONS 15454 M6 Shelf
DLP-G682 Connect the ONS 15454 M6 as the Node Controller in a Mixed Multishelf Configuration Using the Catalyst 3560
