Step 2 Complete the DLP-G577 Remove the Standard Door of the ONS 15454 M6 Shelf , on page 60.
Stop. You have completed this procedure.
DLP-G576 Open the Standard Door of the ONS 15454 M6 Shelf
This task opens the standard door of the ONS 15454 M6 shelf.Purpose
#2 Phillips Dynamometric screwdriverTools/Equipment
• NTP-G252 Install the ONS 15454 M6 Shelf , on page 24
• Connect the chassis to the office ground. For detailed instructions on how
to ground the chassis, see the Electrostatic Discharge and Grounding Guide
for Cisco CPT and Cisco ONS Platforms.
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
The ONS 15454 M6 shelf has an ESD plug input and is shipped with an ESD wrist strap. The ESD plug input
is located on the outside of the shelf on the left side. It is labeled “ESD” on the top and bottom. Always wear
an ESD wrist strap and connect the strap to the ESD plug when working on the ONS 15454 M6. For detailed
instructions on how to wear the ESD wristband, see the Electrostatic Discharge and Grounding Guide for
Cisco CPT and Cisco ONS Platforms.
Note
Procedure
Step 1 Loosen the standard door screws to a torque value of 6.5 in-lb (0.75 N-m) (see the following figure).
Step 2 Push the latches in the opposite direction as shown in the following figure.
Installing the ONS 15454 M6 Shelf
58
Installing the ONS 15454 M6 Shelf
DLP-G576 Open the Standard Door of the ONS 15454 M6 Shelf
