Administration: Discovery
Discover - LLDP
127 Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x
8
• VLAN ID—VLAN ID for which the network policy is defined.
• VLAN Type—VLAN type, Tagged or Untagged, for which the network policy is
defined.
• User Priority—Network policy user priority.
• DSCP—Network policy DSCP.
STEP 4 Select a port and click LLDP Port Status Table to see the details in the LLDP Port Status
Table.
LLDP Statistics
The LLDP Statistics page displays LLDP statistical information per port.
To view the LLDP statistics:
STEP 1 Click Administration > Discovery - LLDP > LLDP Statistics.
For each port, the fields are displayed:
• Interface—Identifier of interface (can also be the OOB port).
• Tx Frames (Total)—Number of transmitted frames.
• Rx Frames
- Total—Number of received frames.
- Discarded—Total number of received frames that discarded.
- Errors—Total number of received frames with errors.
• Rx TLVs
- Discarded—Total number of received TLVs that discarded.
- Unrecognized—Total number of received TLVs that unrecognized.
• Neighbor's Information Deletion Count—Number of neighbor ageouts on the
interface.
STEP 2 Click Refresh to view the latest statistics.

Cisco SG350X-24 Specifications

General

Model	SG350X-24
Layer	Layer 3
Power Supply	Internal
Rack Mountable	Yes
RAM	512 MB
Flash Memory	256 MB
MAC Address Table	16K entries
Power over Ethernet (PoE)	No
Uplink Ports	4 x 10 Gigabit Ethernet
Jumbo Frame Support	Yes
Power Dedicated to PoE	Not applicable
Dimensions	440 x 44 x 350 mm
Stacking	Yes
Operating Temperature	0°C to 45°C
Storage Temperature	-20°C to 70°C
Relative Humidity	10% to 90% (non-condensing)
Power Consumption	30W (maximum)
