Administration: Discovery
Discover - LLDP
Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 128
8
LLDP Overloading
LLDP adds information as LLDP and LLDP-MED TLVs into the LLDP packets. LLDP
overload occurs when the total amount of information to be included in a LLDP packet exceed
the maximum PDU size supported by an interface.
The LLDP Overloading page displays the number of bytes of LLDP/LLDP-MED information,
the number of available bytes for additional LLDP information, and the overloading status of
every interface.
To view LLDP overloading information:
STEP 1 Click Administration > Discovery - LLDP > LLDP Overloading.
This page contains the following fields for each port:
Interface—Port identifier. This can also be an OOB port.
Total Bytes In-Use—Total number of bytes of LLDP information in each packet
Available Bytes Left—Total number of available bytes left for additional LLDP
information in each packet.
Status—Whether TLVs are being transmitted or if they are overloaded.
STEP 2 To view the overloading details for a port, select it and click Details.
This page contains the following information for each TLV sent on the port:
LLDP Mandatory TLVs
- Size (Bytes)—Total mandatory TLV byte size.
- Status—If the mandatory TLV group is being transmitted, or if the TLV group was
overloaded.
LLDP MED Capabilities
- Size (Bytes)—Total LLDP MED capabilities packets byte size.
- Status—If the LLDP MED capabilities packets sent, or if they overloaded.
LLDP MED Location
- Size (Bytes)—Total LLDP MED location packets byte size.
- Status—If the LLDP MED locations packets sent, or if they overloaded.
LLDP MED Network Policy
