Access Control

IPv4-based ACL Creation

Cisco Sx350, SG350X, SG350XG, Sx550X & SG550XG Series Managed Switches, Firmware Release 2.2.5.x 578

The IPv4-based ACL page enables adding ACLs to the system. The rules are defined in the

IPv4-Based ACE page.

IPv6 ACLs are defined in the IPv6 Based ACL page.

IPv4-based ACL

To define an IPv4-based ACL:

STEP 1 Click Access Control > IPv4-Based ACL.

This page contains all currently defined IPv4-based ACLs.

STEP 2 Click Add.

STEP 3 Enter the name of the new ACL in the ACL Name field. The names are case-sensitive.

STEP 4 Click Apply. The IPv4-based ACL is saved to the Running Configuration file.

IPv4-Based ACE

NOTE Each IPv4-based rule consumes one TCAM rule. Note that the TCAM allocation is performed

in couples, such that, for the first ACE, 2 TCAM rules are allocated and the second TCAM rule

is allocated to the next ACE, and so forth.

To add rules (ACEs) to an IPv4-based ACL:

STEP 1 Click Access Control > IPv4-Based ACE.

STEP 2 Select an ACL, and click Go. All currently-defined IP ACEs for the selected ACL are

displayed.

STEP 3 Click Add.

STEP 4 Enter the parameters.

• ACL Name—Displays the name of the ACL.

• Priority—Enter the priority. ACEs with higher priority are processed first.

• Action—Select the action assigned to the packet matching the ACE. The options are as

follows:

- Permit—Forward packets that meet the ACE criteria.
