Cisco Small Business Pro series

Viewing the Gateway Status
Wireless Client Information
SRP 521 VoIP Gateway Administration Guide 111
9
REVIEW DRAFT — CISCO CONFIDENTIAL
Wireless Client Information
You can view wireless client information from the configuration utility.
STEP 1 Click Status on the tab and then click Wireless Client Information in the navigation
pane. The Wireless Client Information page appears.
Field Description
Interface List
Interface The current VLAN interface including the LAN and WAN
side.
Connect Type The kind of protocol to use/apply on this interface.
IP Address The IP address of the interface.
Subnet Mask The subnet mask of the interface.
Port List
Interface The current physical port.
TX (pkts) The number of packets transmitted from this port.
RX (pkts) The number of packets received from this port.
Status Any physical connections on this port.
