Setting up the Interfaces of the Gateway
Using the Loopback Interface
SRP 521 VoIP Gateway Administration Guide 45
3
REVIEW DRAFT — CISCO CONFIDENTIAL
Using the Loopback Interface
The Loopback Interface is set on this page. It only allows two loopback interfaces.
STEP 1 Click Interface Setup on the tab and then click Loopback in the navigation pane.
The Loopback page appears.
STEP 2 Click on the loopback icon to change the IP address and subnet mask for each
loopback interface. The Loopback Interface page opens.
STEP 3 Enter the IP Address and Subnet Mask for each interface.
STEP 4 Click Submit to save your settings.
Field Description
WMM Support If you have other devices on your network that support
WMM Support, select Enabled. Otherwise, use the
default setting, Disabled.
No
Acknowledgement
Select Enabled to disable the acknowledgement
feature, so the gateway will not resend data if an error
occurs. Otherwise, use the default setting, Disabled.
