Setting up the Interfaces of the Gateway
Setting up the Wireless LAN
SRP 521 VoIP Gateway Administration Guide 41
3
REVIEW DRAFT — CISCO CONFIDENTIAL
If a network packet is smaller than the preset RTS threshold size, the RTS/CTS
mechanism will not be enabled. The gateway sends Request to Send (RTS)
frames to a particular receiving station and negotiates the sending of a data frame.
After receiving an RTS, the wireless station responds with a Clear to Send (CTS)
frame to acknowledge the right to begin transmission.
STEP 4 Change any settings in the Advanced Wireless for group SSID area.
STEP 5 Click Submit to save your settings.
Field Description
Advanced Wireless for separate SSID
Select a SSID The beacon interval and RTS threshold settings to apply
to the SSID. The default is SSID1.
