Configuring the Network
NAT
SRP 521 VoIP Gateway Administration Guide 55
4
REVIEW DRAFT — CISCO CONFIDENTIAL
Field Description
Application Name The name of the application.
WAN The WAN interface.
LAN The LAN interface.
Triggered Range The starting and ending port numbers of the triggered
port range. Check with the Internet application
documentation for the port number(s) needed.
Forwarded Range Enter the starting and ending port numbers of the
forwarded port range. Check with the Internet
application documentation for the port number(s)
needed.
Enable Click Enabled to enable the applications you have
defined. This is disabled (unchecked) by default.
