Cisco UCS C240 M5 Service Manual

DescriptionFeature
Up to two CPUs from the Intel Xeon Processor Scalable Family. This includes CPUs from
the following series:
•
Intel Xeon Bronze 3XXX Processors
•
Intel Xeon Silver 4XXX Processors
•
Intel Xeon Gold 5XXX Processors
•
Intel Xeon Gold 6XXX Processors
•
Intel Xeon Platinum 8XXX Processors
Central Processor
24 DDR4 DIMM sockets on the motherboard (12 each CPU)Memory
Multi-bit error protection is supportedMulti-bit error protection
BMC, running Cisco Integrated Management Controller (Cisco IMC) firmware.
Depending on your Cisco IMC settings, Cisco IMC can be accessed through the 1-Gb dedicated
management port, the 1-Gb/10-Gb Ethernet LAN ports, or a Cisco virtual interface card.
Baseboard management
Rear panel:
•
One 1-Gb Ethernet dedicated management port (RJ-45 connector)
•
Two 1-Gb/10-Gb BASE-T Ethernet LAN ports (RJ-45 connectors)
The dual LAN ports can support 1 Gbps and 10 Gbps, depending on the link partner
capability.
•
One RS-232 serial port (RJ-45 connector)
•
One VGA video connector port (DB-15 connector)
•
Two USB 3.0 ports
Front panel:
•
One front-panel keyboard/video/mouse (KVM) connector that is used with the KVM
cable, which provides two USB 2.0, one VGA, and one DB-9 serial connector.
Network and management I/O
One dedicated socket (x16 PCIe lane) that can be used to add an mLOM card for additional
rear-panel connectivity.
Modular LOM
The two 1-Gb/10-Gb BASE-T Ethernet LAN ports support the wake-on-LAN (WoL) standard.WoL
Cisco UCS C240 M5 Server Installation and Service Guide
9
Overview
Summary of Server Features
