Replacing HHHL Form-Factor NVMe Solid State Drives
This section is for replacing half-height, half-length (HHHL) form-factor NVMe SSDs in the PCIe risers.
HHHL SSD Population Guidelines
Observe the following population guidelines when installing HHHL form-factor NVMe SSDs:
• Two-CPU systems—You can populate up to 6 HHHL form-factor SSDs, using PCIe slots 1 – 6.
• One-CPU systems—In a single-CPU system, PCIe riser 2 is not available. Therefore, the maximum
number of HHHL form-factor SSDs you can populate is 3, using PCIe slots 1 - 3.
HHHL Form-Factor NVME SSD Requirements and Restrictions
Observe these requirements:
•
All versions of the server support HHHL form-factor NVMe SSDs.
Observe these restrictions:
•
You cannot boot from an HHHL form-factor NVMe SSD.
•
You cannot control HHHL NVMe SSDs with a SAS RAID controller because NVMe SSDs interface
with the server via the PCIe bus.
•
You can combine NVMe SFF 2.5- or 3.5-inch SSDs and HHHL form-factor SSDs in the same system,
but the same partner brand must be used. For example, two Intel NVMe SFF 2.5-inch SSDs and two
HGST HHHL form-factor SSDs is an invalid configuration. A valid configuration is two HGST NVMe
SFF 2.5-inch SSDs and two HGST HHHL form-factor SSDs.
Replacing an HHHL Form-Factor NVMe SSD
In a single-CPU server, PCIe riser 2 (PCIe slot 2) is not available.Note
Step 1
Remove an existing HHHL form-factor NVME SSD (or a blank filler panel) from the PCIe riser:
a) Shut down and remove power from the server as described in Shutting Down and Removing Power From the Server,
on page 39.
Cisco UCS C240 M5 Server Installation and Service Guide
66
Maintaining the Server
Replacing HHHL Form-Factor NVMe Solid State Drives
