Cisco UCS C240 M5 Service Manual

Rear NVMe cable connector
(on riser version 2B, 2C, or 2D only)
2Front NVMe cable connector
(on riser version 2C only)
1
Replacing Rear-Loading NVMe SSDs
This section is for replacing 2.5-inch form-factor NVMe solid-state drives (SSDs) in rear-panel drive bays.
This section contains the following topics:
Rear-Loading NVMe SSD Population Guidelines
The rear drive bay support differs by server PID and which type of RAID controller is used in the server for
non-NVMe drives:
• UCSC-C240-M5SX—Small form-factor (SFF) drives, with 24-drive backplane.
◦ Hardware RAID—Rear drive bays support SAS or NVMe drives
◦ Embedded software RAID—Rear drive bays support NVMe drives only.
• ◦
• UCSC-C240-M5S—SFF drives, with 8-drive backplane and DVD drive option.
◦ Hardware RAID—Rear drive bays support SAS or NVMe drives
◦ Embedded software RAID—Rear drive bays support NVMe drives only.
• UCSC-C240-M5L—Large form-factor (LFF) drives, with 12-drive backplane.
◦ Hardware RAID—Rear drive bays support SAS or NVMe drives
◦ Embedded software RAID—Rear drive bays support NVMe drives only.
•
The rear drive bay numbering follows the front-drive bay numbering in each server version:
◦ 8-drive server—rear bays are numbered bays 9 and 10.
◦ 12-drive server—rear bays are numbered bays 13 and 14.
◦ 24-drive server—rear bays are numbered bays 25 and 26.
•
When populating drives, add drives to the lowest-numbered bays first.
•
Keep an empty drive blanking tray in any unused bays to ensure proper airflow.
Cisco UCS C240 M5 Server Installation and Service Guide
59
Maintaining the Server
Replacing Rear-Loading NVMe SSDs
