Cisco UCS C240 M5 Service Manual

Nominal range: 200–240 VAC
(Range: 180–264 VAC)
AC Input Voltage
Nominal range: 50 to 60Hz
(Range: 47–63 Hz)
AC Input Frequency
9.5 A at 200 VACMaximum AC Input current
1250 VA at 200 VACMaximum input volt-amperes
30 A at 35° CMaximum inrush current
80 ms at 1600 WMaximum hold-up time
1600 W at 200–240 VAC
Maximum output power per PSU
12 VDCPower supply output voltage
12 VDCPower supply standby voltage
Climate Savers Platinum Efficiency (80Plus Platinum certified)Efficiency rating
RSP2Form factor
IEC320 C14Input connector
1050 W DC Power Supply
This section lists the specifications for each 1050 W DC power supply (Cisco part number
UCSC-PSUV2-1050DC).
Table 15: 1050 W DC Specifications
SpecificationDescription
Nominal range: -48 to -60 VDC
(Range: -40 to -72 VDC)
DC Input Voltage
N32 A at -40 VDCMaximum DC input current
1234 WMaximum input wattage
35 A (sub-cycle duration)Maximum inrush current
5 ms at 100% load (1050 W main and 36 W standby)Maximum hold-up time
Cisco UCS C240 M5 Server Installation and Service Guide
124
Server Specifications
Power Specifications

Cisco UCS C240 M5 Specifications

General

Form Factor	2U Rack
Storage Controllers	Cisco 12G SAS Modular RAID Controller
Management	Cisco Integrated Management Controller (CIMC)
Processor	Intel Xeon Scalable Processors
Memory	Up to 3TB DDR4
Drive Bays	Up to 12 x 3.5-inch drives
