Chapter 3 Maintaining the Server
Installing or Replacing Server Components
Figure 3-9 Removing and Replacing a SAS Riser
Figure 3-10 SAS Riser Card Connectors
1 Retaining clip 2 SAS riser
198885
21
1 SAS cable connectors
JT6 = Ports 0 - 3
JT7 = Ports 4 - 7
2 LSI BBU connector JT3
(on LSI 9260-8i only)
JT7 JT6
JT3
1 2
198973
