3-33
Cisco UCS C460 Server Installation and Service Guide
OL-22326-01z
Chapter 3 Maintaining the Server
Installing or Replacing Server Components
Figure 3-23 Removing and Replacing Fan Modules
Replacing Hard Drives or Solid State Drives
Tip You do not have to shut down or power off the server to replace hard drives or SSDs because they are
hot pluggable.
Note You can mix hard drives and solid state drives (SSDs) in the same server. However, You cannot configure
a logical volume (virtual drive) that contains a mix of hard drives and SSDs. That is, when you create a
logical volume, it must contain all hard drives or all SSDs.
Note Cisco recommends following the industry-standard practice of using drives of the same capacity when
configuring RAID volumes. If you use drives of different capacities, the usable portion of the smallest
drive will be used on all drives of the RAID volume.
Note The 500 GB SATA drives (A03-D500GC3) and the 1 TB SATA drives (A03-D1TBSATA) that are sold
with the UCS C460 M2 server are supported at full 6G speeds.
The qualified and supported part numbers for this component are subject to change over time. For the most
up-to-date list of replaceable components, see the following URL and then scroll to Technical Specifications:
1 Fan module release latches 2 Fan module, front view showing connector on
underside of the module
