3-42
Cisco UCS C460 Server Installation and Service Guide
OL-22326-01
Chapter 3 Maintaining the Server
Installing or Replacing Server Components
Special Considerations for Cisco UCS Virtual Interface Cards
Table 3-5 describes the requirements for the supported Cisco UCS virtual interface cards (VICs).
Special Considerations for Cisco UCS Fusion ioDrive2 Storage Accelerator Cards
Table 3-6 describes the requirements for the supported Cisco UCS Fusion ioDrive2 cards.
Note PCIe slots 8 and 10 are Gen1 x4 electrical lane width slots and provide limited bandwidth if used with
these cards.
Ta b l e 3-5 Cisco UCS C460 Requirements for Virtual Interface Cards
Virtual Interface
Card (VIC)
Number of
VICs
Supported
in Server
Slots That
Support
VICs
1
1. See PCIe Slots, page 3-38.
Primary Slot For
UCS Integration
or Cisco Card
NIC Mode
Minimum
CIMC
Firmware
Minimum VIC
Firmware For
Use With UCS
Integration
Minimum Nexus
OS on an Upstream
Nexus Fabric
Interconnect
Cisco UCS VIC P81E
N2XX-ACPCI01
2 PCIE 1
PCIE 2
PCIE 1 1.4(3) 2.0(2) 5.0
Cisco UCS VIC 1225
UCSC-PCIE-CSC-02
2 PCIE 1
PCIE 2
PCIE 1 1.4(6) 2.1(0) 5.0
Cisco UCS VIC1225T
UCSC-PCIE-C10T-02
2 PCIE 1
PCIE 2
PCIE 1
2
2. The Cisco UCS VIC1225T is not supported for UCS integration at this time.
1.5(1) 2.1(1) 5.0
Ta b l e 3-6 Cisco UCS C460 Requirements for Fusion ioDrive2 Cards
Card
Max. Number of
Cards Supported
Slots That
Support Cards
1
1. See PCIe Slots, page 3-38.
Minimum CIMC
Firmware
Card Height
(rear-panel tab)
Cisco UCS 3.0 TB MLC Fusion ioDrive2
UCSC-F-FIO-3000M
10 All
2
2. See note below regarding slots 8 and 10.
1.5(2) Full height
Cisco UCS 1205 GB MLC Fusion ioDrive2
UCSC-F-FIO-1205M
10 All 1.5(2) Half height
3
3. A rear-panel tab adapter is required to fit the half-height cards in the full-height slots.
Cisco UCS 785 GB MLC Fusion ioDrive2
UCSC-F-FIO-785M
10 All 1.5(2) Half height
Cisco UCS 365 GB MLC Fusion ioDrive2
UCSC-F-FIO-365M
10 All 1.5(2) Half height
