Chapter 3 Maintaining the Server
Installing or Replacing Server Components
d. Press the lightpipe switch that is on the top of the plastic divider for the hot-swappable PCIe slot.
Note Wait for the lightpipe switch LED to turn off before removing the card in the next step.
e. Pinch and lift up the green retaining clip that secures the card to the chassis rear panel.
f. Lift the card straight up from the motherboard connector.
Note Lift up on both ends of the card evenly to avoid damaging its connector.
Step 2 Install a hot-swappable PCIe card:
a. Align the PCIe card with the empty PCIe connector on the motherboard.
b. Push down evenly on both ends of the card until it is fully seated in the motherboard connector.
c. Ensure that the card rear panel sits flat against the server back panel opening.
d. Push the green retaining clip down until it locks over the top of the card.
e. Press the lightpipe switch that is on top of the plastic divider for the hot-swappable PCIe slot. Wait
for the LED to turn on to ensure that the PCIe slot receives power.
f. Replace the top cover.
g. Replace the server in the rack and replace cables.
