3-27
Cisco UCS C460 Server Installation and Service Guide
OL-22326-01z
Chapter 3 Maintaining the Server
Installing or Replacing Server Components
c. Simultaneously press down on each release lever to put them in the locked position. This ensures
that the riser is properly seated in the motherboard connector.
d. Press the attention button, then wait until the attention LED turns off.
e. Replace the top cover.
f. Replace the server in the rack and replace any cables.
Figure 3-17 Removing and Replacing Memory Risers
1 Memory riser release buttons 2 Memory riser release latches
