Send document comments to ucs-docfeedback@cisco.com
1-11
Cisco UCS 6100 Series Fabric Interconnect Hardware Installation Guide
OL-20036-02
Chapter 1 Product Overview
Expansion Modules
through 20 are encryption-capable Ethernet ports. Group 2 includes the ports in the expansion module
or modules. Group 2 ports 1 through 4 are encrypted Ethernet ports. Group 2 ports 5 through 8 are Fibre
Channel ports.
Figure 1-15 shows how ports are numbered and grouped by function on a Cisco UCS 6120XP with the
N10-E0440 expansion module installed.
Figure 1-15 Port Numbering of the Cisco UCS 6120XP Configured with the N10-E0440 Expansion
Module
Figure 1-16 shows how ports are numbered and grouped by function with the N10-E0600 expansion
module installed.
Figure 1-16 Port Numbering of the Cisco UCS 6120XP Configured with the N10-E0600 Expansion
Module
A Group 1 ports 1 through 8: 10-Gigabit or
1-Gigabit Ethernet capable unencrypted ports
D Group 2 ports 1 through 4: Encrypted
Ethernet ports
B Group 1 ports 1 through 16: Unencrypted
Ethernet ports
E Group 2 ports 5 through 8: Fibre Channel
ports
C Group 1 ports 17 through 20: Encrypted
Ethernet ports
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
A B C D E
192241
A Group 1 ports 1 through 8: 10-Gigabit or 1
Gigabit Ethernet capable unencrypted ports
D Group 2 ports 1 through 4: Encrypted
Ethernet ports
B Group 1 ports 1 through 16: Unencrypted
Ethernet ports
E Group 2 ports 5 and 8: Unencrypted Ethernet
ports
C Group 1 ports 17 through 20: Encrypted
Ethernet ports
1
2
3
4
5
6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
A B C D E
192242
