Send document comments to ucs-docfeedback@cisco.com
A-3
Cisco UCS 6100 Series Fabric Interconnect Hardware Installation Guide
OL-20036-02
Appendix A Technical Specifications
Transceiver Specifications
Transceiver Specifications
Table A-4 lists general specifications for the 10-Gigabit Ethernet SFP+ transceiver module.
Specifications for these transcievers is at:
http://www.cisco.com/en/US/docs/interfaces_modules/transceiver_modules/installation/note/78_15160
.html
Environmental Conditions and Power Requirement Specifications for SFP+
Transceivers
Table A-5 lists the environmental conditions and power requirement specifications for the 10-Gigabit
Ethernet SFP+ transceiver module.
General Specifications for Cisco Fibre Channel SFP Transceivers
Table A-6 lists the general specifications for Cisco Fibre Channel SFP transceivers at 4 Gbps.
Ta b l e A-4 General Specifications for the 10-Gigabit Ethernet SFP+ Transceiver Module
Description Short Range
Connector type LC
Wavelength 850 nm
Core size—Cable distance 50 microns—300 m 62.5 microns—33 m
Ta b l e A-5 Environmental Conditions and Power Requirement Specifications for the 10-Gigabit
Ethernet SFP+ Transceiver Module
Parameter Symbol Minimum Maximum
Storage temperature T
S
-40°C (-40°F) 85°C (185°F)
Case temperature T
C
0°C (32°F) 70°C (158°F)
Relative humidity RH 5 % 95 %
Module supply voltage V
CC
T,R 3.1 V 3.5 V
Ta b l e A-6 General Specifications for Cisco Fibre Channel SFP Transceivers at 4 Gbps
Description Short Wavelength
Connector type LC
Wavelength 850 nm
Fibre type MMF
Core size—Cable distance
1
1. Approximate; actual distance may vary depending on fiber quality and other factors.
50 microns—328.08 yd (300 m) 62.5 microns—164.04 yd (150 m)
Transmit power -9 to -2.5 dBM
