Send document comments to ucs-docfeedback@cisco.com
B-1
Cisco UCS 6100 Series Fabric Interconnect Hardware Installation Guide
OL-20036-02
APPENDIX
B
Cable and Port Specifications
This appendix provides cable and port specifications, and includes the following sections:
• Accessory Kit for the Cisco UCS Fabric Interconnect, page B-1
• Console Port, page B-2
• Supported Power Cords and Plugs, page B-3
• Jumper Power Cord, page B-8
Accessory Kit for the Cisco UCS Fabric Interconnect
The Cisco UCS 6120XP 20-Port Fabric Interconnect accessory kit includes the following items:
• 2 slider rails
• 2 rack-mount guides
• 2 rack-mount brackets
• 12 M4 x 0.7 x 8-mm Phillips countersunk screws
• 10 10-32 rack nuts
• 10 10-32 x 3/4-inch Phillips pan-head screws
• 1 console cable with an RJ-45-RS-232 adapter and a DB9 adapter
• 1 ground lug kit
• 1 ESD wrist strap
• 1 pointer document (specifies where to find the online product documentation)
Note Additional parts can be ordered from your customer service representative.
