Send document comments to ucs-docfeedback@cisco.com
2-29
Cisco UCS 6100 Series Fabric Interconnect Hardware Installation Guide
OL-20036-02
Chapter 2 Installing the Cisco UCS 6100 Series Fabric Interconnect
Replacing or Installing Components
Note If you purchased this product through a Cisco reseller, contact the reseller directly for technical support.
If you purchased this product directly from Cisco, contact Cisco Technical Support at this URL:
http://www.cisco.com/en/US/support/tsd_cisco_worldwide_contacts.html.
Preparing a Fabric Interconnect for Removal
Removing a standby fabric interconnect is non-disruptive to a UCS system. Removing an active fabric
interconnect will cause the standby fabric interconnect to become active with minimal or no disruption.
Be aware that if you remove both the active and standby fabric interconnect from a UCS system, or the
sole fabric interconnect from a standalone system, you are shutting down the entire UCS instance. Before
doing this, perform the following tasks:
1. Perform a backup of your UCS Manager configuration as discussed in the “System Management“
section, “Backing Up and Restoring the Configuration” chapter of the UCS Manager configuration
guide for your software release.
1. Use UCS Manager to shut down the OS on all servers in the UCS instance. Graceful shutdown of a
blade server is discussed in the “System Management“ section, “Managing Blade Servers” chapter
of the UCS Manager configuration guide for your software release. The related CLI commands are:
UCS-A# scope org
UCS-A /org # scope service-profile
service-profile-name
UCS-A /org/service-profile # power down
2. Disable the Smart Call Home feature, as mentioned in the “System Monitoring” section,
“Configuring Call Home” chapter of the UCS Manager configuration guide for your software
release. The related CLI commands are:
UCS-A# scope monitoring
UCS-A /monitoring # scope callhome
UCS-A /monitoring/callhome # disable
3. Decommision every attached chassis as described in the “System Management“ section, “Managing
the Chassis“ chapter of the UCS Manager configuration guide for your software release. The related
CLI command is decommission-chassis chassis-num .
4. Power down every attached chassis as decribed in the installation chapter of the Cisco UCS 5108
Server Chassis Installation Guide.
When powering down and removing clustered fabric interconnects, remove the secondary first, and then
remove the primary.
Removing a Cisco UCS 6120XP
Caution The slider rail and front rack-mount brackets do not have a stop mechanism when sliding in and out. If
the front of the chassis is unfastened from the rack and the chassis slides forward on the slider rails, it
may slip off the end of the rails and fall out of the rack.
