CHAPTER
Send document comments to ucs-docfeedback@cisco.com
2-1
Cisco UCS 6100 Series Fabric Interconnect Hardware Installation Guide
OL-20036-02
2
Installing the Cisco UCS 6100 Series Fabric
Interconnect
This chapter describes how to install Cisco UCS 6100 Series Fabric Interconnect, and it includes the
following sections:
• Preparing for Installation, page 2-2
• Installing the Cisco UCS 6120XP Chassis in a Cabinet or Rack, page 2-6
• Grounding the System, page 2-11
• Grounding the Chassis, page 2-18
• Starting the System, page 2-20
• Replacing or Installing Components, page 2-22
• Repacking the Cisco UCS Fabric Interconnect for Return Shipment, page 2-30
Note Before you install, operate, or service the system, read the Regulatory Compliance and Safety
Information for the Cisco UCS for important safety information.
Warning
IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar
with standard practices for preventing accidents. Use the statement number provided at the end of
each warning to locate its translation in the translated safety warnings that accompanied this device.
Statement 1071
SAVE THESE INSTRUCTIONS
Warning
This unit is intended for installation in restricted access areas. A restricted access area can be
accessed only through the use of a special tool, lock and key, or other means of security.
Statement 1017
Warning
Only trained and qualified personnel must be allowed to install, replace, or service this equipment.
Statement 1030
