— 17 —
1
Turn off the power of the printer.
2
Open the printer cover.
3
Take off 2 screws and remove
printer cover.
4
Take off damper retention screws,
reposition damper (11 mm) in the
direction of the bold arrow, then
secure it with the original screws
again.
5
Replace printer cover on printer.
6
Install the supplied partition into the
position as illustrated.
7
Change DIP switch setting for 58-
mm roll paper, by referring to
“5. SETTING DIP SWITCHES”.
4.6 Using 58 mm Wide Paper Rolls
Printer cover
CAUTION:
Do not change DIP switch setting from 58-mm into 80-mm roll paper in the middle of
printing.
Damper
Partition
To Next Page
