— 23 —
1
Turn off the power of the printer.
2
Open the printer cover.
3
Remove the paper roll.
4
While pulling the tab of the DIP
switch cover (To unlock it), lift out
the cover.
5
To change settings refer to the
following pages.
6
After completing the setting
changes turn on power source.
The new settings are now enabled.
5. SETTING DIP SWITCHES
5.1 Location of DIP Switches
DIP switch cover
Tab
To access the DIP switches, follow these steps:
To Next Page
