Page #218 background image
— 200 —
6.1.3 Belegung der Anschlußstifte
Verwendbare Anschlüsse
Druckerseitig: 57LE-40360 (Amphenol) oder äquivalente Anschlüsse
Kabelseitig: 57-30360 (Amphenol) oder äquivalente Anschlüsse
Der Quelle
KompatibilitätsModus
Nibble-Modus
Byte-Modus
1 Host nStrobe HostClk HostClk
2 Host/Ptr Data0(LSB) Data0(LSB) Data0(LSB)
3 Host/Ptr Data1 Data1 Data1
4 Host/Ptr Data2 Data2 Data2
5 Host/Ptr Data3 Data3 Data3
6 Host/Ptr Data4 Data4 Data4
7 Host/Ptr Data5 Data5 Data5
8 Host/Ptr Data6 Data6 Data6
9 Host/Ptr Data7(MSD) Data7(MSD) Data7(MSD)
10 Printer nAck PtrClk PtrClk
11 Printer Busy PtrBusy/Data3.7 PtrBusy
12 Printer PEerror AckDataReq/Data2.6 AckDataReq
13 Printer Select Xflag/Data1.5 Xflag
14 Host nAutoFd HostBusy HostBusy
15 NC ND ND
16 GND GND GND
17 FG FG FG
18 Printer +5V +5V +5V
19 GND GND GND
20 GND GND GND
21 GND GND GND
22 GND GND GND
23 GND GND GND
24 GND GND GND
25 GND GND GND
26 GND GND GND
27 GND GND GND
28 GND GND GND
29 GND GND GND
30 GND GND GND
31 Host nInit nInit nInit
32 Printer nFault nDataAvail/Data0.4 nDataAvail
33 GND ND ND
34 Printer DK_STATUS ND ND
35 Printer +5V ND ND
36 Host nSelectIn 1284-Active 1284-Active
NC: Nicht angeschlossen
ND: Nicht definiert
