Citizen CL-E321 Programming Manual

CITIZEN Android Label Print SDK — Programming Manual
13
Methods (LabelDesign class)
No
Method
Description
1
LabelDesign
Constructor.
2
drawTextPtrFont
Draws text by using a printer device font.
3
drawTextDLFont
Draws text by using a downloaded font.
4
drawTextLocalFont
Draws text by using a font installed in the terminal.
5
drawNVBitmap
Draws a bitmap image stored in the flash memory of the printer.
6
drawBitmap
Draws a bitmap file in the computer.
7
drawBarCode
Draws a barcode.
8
drawMaxiCode
9
drawPDF417
10
drawDataMatrix
11
drawQRCode
12
drawAztec
13
drawGS1DataBar
14
drawLine
Draws a line.
15
drawRect
Draws a rectangular.
16
fillRect
Draws a rectangular filled with a specified pattern.
17
drawCircle
Draws a circle.
18
fillCircle
Draws a circle filled with a specified pattern.
19
drawPolygon
Draws a polygon.
20
fillPolygon
Draws a polygon filled with a specified pattern.
21
embedRawDesignCommand
Embeds raw printer commands.

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
