Citizen CL-E321 Programming Manual

CITIZEN Android Label Print SDK — Programming Manual
41
2.2.24 VerticalOffset property
Syntax
int VerticalOffset
Attribute
Read/Write
Description
Sets the vertical offset to adjust the vertical printing position on the paper.
Inch system 0000 – 9999 (0.00 inch - 99.99 inches)
Metric system 0000 – 9999 (0.0 mm - 999.9 mm)
Default value 0000
Setter method
int setVerticalOffset (int verticalOffset)
Returns CLS_SUCCESS (0) on success. See "2.1 Return value" for the error codes.
Getter method
int getVerticalOffset ()
Returns the set value. If nothing has been set, it returns CLS_PROPERTY_DEFAULT(999999).
Example
int verticalOffset;
printer.setVerticalOffset(10);
verticalOffset = printer.getVerticalOffset();

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
