CITIZEN Android Label Print SDK — Programming Manual
79
2.3.15 drawRect method
Syntax
int drawRect (int x, int y, int width, int height, int thickness)
Parameters
Parameter
[IN/OUT]
Description
Setting range
x
[IN]
Start position
(X-coordinate)
0000 - 9999
* The origin is at bottom-left.(0, 0)
y
[IN]
Start position
(Y-coordinate)
width
[IN]
Box width
0000 - 9999
height
[IN]
Box height
thickness
[IN]
Line width
0000 - 9999
Description
Draws a box of the specified width, height and line width. Thicker line width expands the line inward
and doesn't affect the outline size.
Return value
Returns CLS_SUCCESS(0) on success, an error code otherwise. See "2.1 Return value" for the error
codes.
Example
design.drawRect(20, 30, 180, 280, 10);

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
