Citizen CL-E321 Programming Manual

CITIZEN Android Label Print SDK — Programming Manual
38
2.2.21 BackupSpeed property
Syntax
int BackupSpeed
Attribute
Read/Write
Description
Sets the backup speed. See below for the acceptable values.
Value
Description
CLS_SPEEDSETTING_A or
CLS_SPEEDSETTING_B
1.0 inch( 25.4mm) / sec
CLS_SPEEDSETTING_C or
CLS_SPEEDSETTING_D
2.0 inch( 50.8mm) / sec
CLS_SPEEDSETTING_E or
CLS_SPEEDSETTING_F
3.0 inch( 76.2mm) / sec
CLS_SPEEDSETTING_G or
CLS_SPEEDSETTING_H
4.0 inch(101.6mm) / sec
CLS_SPEEDSETTING_I or
CLS_SPEEDSETTING_J
5.0 inch(127.0mm) / sec
CLS_SPEEDSETTING_K or
CLS_SPEEDSETTING_L
6.0 inch(152.4mm) / sec
CLS_SPEEDSETTING_M or
CLS_SPEEDSETTING_N
7.0 inch(177.8mm) / sec
CLS_SPEEDSETTING_O
8.0 inch(203.2mm) / sec
CLS_SPEEDSETTING_1
- CLS_SPEEDSETTING_8
1.0 inch( 25.4mm) / sec - 8.0 inch(203.2mm) / sec
*Initial and maximum value vary depending on the printer model.
Setter method
int setBackupSpeed (int backupSpeed)
Returns CLS_SUCCESS (0) on success. See "2.1 Return value" for the error codes.
Getter method
int getBackupSpeed ()
Returns the set value. If nothing has been set, it returns CLS_PROPERTY_DEFAULT(999999).
Example
int backupSpeed;
printer.setBackupSpeed(LabelConst.CLS_SPEEDSETTING_O);
backupSpeed = printer.getBackupSpeed();

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
