CITIZEN Android Label Print SDK — Programming Manual
73
2.3.10 drawDataMatrix method
Syntax
int drawDataMatrix (String data, int encoding, int rotation, int exp, int ECLevel, int x, int y)
Parameters
Parameter
[IN/OUT]
Description
Setting range
data
[IN]
String data
-Numeric: Up to 3,116 characters
-Alphanumeric: Up to 2,335 characters
* The characters available with the specified
encoding.
encoding
[IN]
Character encoding
See #9 in "3.3.Predefined Constants."
rotation
[IN]
Direction of rotation
CLS_RT_NORMAL: No rotation
CLS_RT_RIGHT90: Rotate CW 90
CLS_RT_ROTATE180: Rotate CW 180
CLS_RT_LEFT90: Rotate CCW 90
exp
[IN]
Magnification
1-15
ECLevel
[IN]
Error correction level
CLS_DATAMATRIX_EC_LEVEL_200： 200
x
[IN]
X-coordinate
0000-9999
* The origin is at bottom-left.(0, 0)
y
[IN]
Y-coordinate
Description
Draws the DataMatrix barcode with specifying options such as character encoding, rotation,
magnification, EC level and coordinates.
Return value
Returns CLS_SUCCESS(0) on success, an error code otherwise. See "2.1 Return value" for the error
codes.
Example
design.drawDataMatrix("0123456789",
LabelConst.CLS_ENC_CDPG_US_ASCII,
LabelConst.CLS_RT_NORMAL, 15,
LabelConst.CLS_DATAMATRIX_EC_LEVEL_200, 0, 0);

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
