Citizen CL-E321 Programming Manual

CITIZEN Android Label Print SDK — Programming Manual
72
2.3.9 drawPDF417 method
Syntax
int drawPDF417 (String data, int encoding, int rotation, int exp, int ECLevel, int x, int y)
Parameters
Parameter
[IN/OUT]
Description
Setting range
data
[IN]
String data
* The characters available with the
specified encoding.
encoding
[IN]
Character encoding
See "3.3.Predefined Constants."
rotation
[IN]
Direction of rotation
CLS_RT_NORMAL: No rotation
CLS_RT_RIGHT90: Rotate CW 90
CLS_RT_ROTATE180: Rotate CW 180
CLS_RT_LEFT90: Rotate CCW 90
exp
[IN]
Magnification
1-5
ECLevel
[IN]
Error correction level
CLS_PDF417_EC_LEVEL_0： Level 0
CLS_PDF417_EC_LEVEL_1： Level 1
CLS_PDF417_EC_LEVEL_2： Level 2
CLS_PDF417_EC_LEVEL_3： Level 3
CLS_PDF417_EC_LEVEL_4： Level 4
CLS_PDF417_EC_LEVEL_5： Level 5
CLS_PDF417_EC_LEVEL_6： Level 6
CLS_PDF417_EC_LEVEL_7： Level 7
CLS_PDF417_EC_LEVEL_8： Level 8
x
[IN]
X-coordinate
0000-9999
* The origin is at bottom-left.(0, 0)
y
[IN]
Y-coordinate
Description
Draws the PDF417 barcode with specifying options such as character encoding, rotation,
magnification, EC level and coordinates.
Return value
Returns CLS_SUCCESS(0) on success, an error code otherwise. See "2.1 Return value" for the error
codes.
Example
design.drawPDF417("0123456789",
LabelConst.CLS_ENC_CDPG_US_ASCII,
LabelConst.CLS_RT_NORMAL, 3,
LabelConst.CLS_PDF417_EC_LEVEL_0, 0, 0);

Citizen CL-E321 Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Power Supply	100-240V AC, 50/60 Hz
Max Print Width	4.1 inches (104 mm)
Media Sensor	Transmissive and reflective sensor
Interface	USB, Serial (RS-232)
Media Width	1.97 to 4.33 inches (50 to 110 mm)
Supported Barcode Types	Code 39, Code 128, ITF, Codabar, UPC-A, UPC-E, EAN-8, EAN-13, POSTNET
Supported Media Types	Continuous, Die-cut
Media Thickness	0.0635 – 0.254 mm (2.5 - 10 mil)
Print Speed	Up to 8 inches per second
