Citizen SA-SD - 2 Product Overview; Outline

2 - 1
2. Product Overview
2-1 Outline
When connected to a detector, the SA-SD controller can be used to measure size and perform
pass/fail judgments.
Controller
Model Characteristics Power supply
Pass/
fail output
Input/output
SA-SD1AP Master/high performance Power cable Yes NPN
SA-SD1AP-P Master/high performance Connected master Yes PNP
SA-SD1AC Slave/high performance Connected master Yes NPN
SA-SD1AC-P Slave/high performance Connected master Yes PNP
SA-SD1C Slave/standard type Connected master Yes NPN
SA-SD1C-P Slave/standard type Connected master Yes PNP
SA-SDNC Slave/wire-saving type Connected master No −
Connectable detectors (sold separately)
Caution
■
Do not connect this device to any product other than those listed below. Connection to
other products may result in an accident or failure.
Model Characteristics
Measurement
range
Resolution
Indication
accuracy
SA-S110 High precision/slim type 10 mm 0.1 µm 1.0 µm
SA-S110/03N High precision/slim type/low performance 10 mm 0.1 µm 1.0 µm
SA-S510 Universal slim type 10 mm 0.5 µm 2.0 µm
SA-S510/03N Universal slim type/low performance 10 mm 0.5 µm 2.0 µm
Resolution settings and detector replacement
Resolution varies depending on the detector that is connected. Connection of the detector is detected
automatically. As a result, there is no need to perform the parameter setting procedure required with
previous products.
Be sure to turn off the power before replacing with a different detector, and adjust the new detector and
master prior to use.
Optional parts (sold separately)
Model Name Description
SA-SD-SH2M Detector connection cable Straight connector: 2 m
SA-SD-SH5M Detector connection cable Straight connector: 5 m
SA-SD-SH10M Detector connection cable Straight connector: 10 m
SA-SD-SHL2M Detector connection cable L-type connector: 2 m
SA-SD-SHL5M Detector connection cable L-type connector: 5 m
SA-SD-SHL10M Detector connection cable L-type connector: 10 m
■
■
■
