7- 1
7. External Input/Output
7-1 Interface
7-1-1 Input/Output Circuit
SA-SD1AP, SA-SD1AP-P
Color Signal I/O Remarks
Brown +V − 24 VDC
Black Output 1 OUT
Refer to "6-2-4 External Output." White Output 2 OUT
Black/gray Output 3 OUT
Pink External input 1 IN
Refer to "6-2-3 External Input." Violet External input 2 IN
Pink/violet External input 3 IN
Blue 0 V − Ground for power supply
Gray Analog output OUT Current output (4 to 20 mA)
Shield Analog ground −
Note 1: Use shielded wires for analog outputs.
SA-SD1AC, SA-SD1AC-P
Color Signal I/O Remarks
Black Output 1 OUT
Refer to "6-2-4 External Output." White Output 2 OUT
Black/gray Output 3 OUT
Pink External input 1 IN
Refer to "6-2-3 External Input."
Violet External input 2 IN
Pink/violet External input 3 IN
Gray Analog output OUT Current output (4 to 20 mA)
Shield Analog ground −
Note 1: Use shielded wires for analog outputs.
SA-SD1C, SA-SD1C-P
Color Signal I/O Remarks
Black Output 1 OUT
Refer to "6-2-4 External Output." White Output 2 OUT
Black/gray Output 3 OUT
Pink External input 1 IN
Refer to "6-2-3 External Input." Violet External input 2 IN
Pink/violet External input 3 IN
Note 1: Power is supplied through master unit connectors.
