6- 4
Calibration settings (CALIB)
Calibration select
(CAL.SEL)
When a sensor head is replaced, carrying out zero and
span adjustment reduces the errors existing at installation
time.
DEFAUL (Default) / USER (Set by user)
[Default: DEFAUL]
∗ When calibration select is set to USER (setting by user)
Captured measurement value
1 (CL.SET1)
The controller moves the spindle to the zero point (which
constitutes the calibration reference), and captures the
measurement value.
Captured measurement value
2 (CL.SET2)
The controller moves the spindle to the target point for span
adjustment, and captures the measurement value.
Adjustment value 2 (AJ.VAL2)
Inputs a target value.
−199.9999 to 199.9999 (mm) [Default: 10.000]
Resetting (RESET)
Reset (RESET)
This resets the controller settings (excluding calibration
settings) to the factory defaults.
YES / NO
Maintenance
Total stroke work history
(SUM.REC)
Displays information such as sensor head operational
history.
Maximum peak value
(MAX.VAL)
Maximum peak value history
(MAX.REC)
Overstroke history
(OVR.NUM)
