clare H101 - Page 20

Beacon – for connection to external warning beacon.
Comms 1 – Communication port 1 for connection to a PC.
Comms 2 - Communication port 2 for connection to a compatible
Barcode reader or scanner.
Comms 3 - Communication port 3 for connection to a Printer.
Test Output – for connection to remote test output box.
F20A(HRC)
F16A(HRC)
T4A
Aux Input
80-300V 50-60 Hz
