clare H101 - Chapter 7 Specifications; Input Rating

C
hapter 7 Specifications
Input Rating
Supply Voltage
selectable 115V/230V a.c. RMS
Frequency
50/60 Hz
Fus
e 3 amps 250V H101 & H102
5 amps 250V H103
2 x 5 amps 250V, 2 x F16A HRC 300V, 2 x 20A HRC 300V HAL 104
Display
Type ¼ VGA Monochrome Graphical
Environmental Specifications
Operating Temperature 0ÝC to +45 ÝC
Storage Temperature -20ÝC to +60 ÝC
Humidity Non Condensing (<10ÝC) 95%
RH
Dust/Water Resistance Min IP40
Mechanical Specification
Size (HxWxL) 300mm-200mm-370mm
Weight 15kg Approx
Safety Specifications
Electrical Safety IEC 1010-1; CAT II 300V,
Pollution Degree II
EMC
RFI Susceptibillity 3 Volts per Meter as per
IEC1000-4-3
Radiation EN61326-1-1998 (Class A)
ESD IEC 801-4
