Chapter 2 Connecting the Tester
Connecting the tester
The Tester may be powered by either a 230V or an 115V supply. This
is selected on the rear panel of the instrument.
The supply must include an earth connection (e.g. via a 3-pin plug).
When switched on, the Tester will carry out a short self-test
procedure (approximately 2 seconds). During this test, the logo will
be displayed on screen along with the system version numbers.
The Tester will then display the Main Menu
