English
NX500/NZ500 55
English
Owner’s Manual
INSTALLATION /WIRE
CONNECTION GUIDE
1. Before Starting
1. This set is exclusively for use in cars with a
negative ground 12V power supply.
2. Read these instructions carefully.
3. Be sure to disconnect the battery“ ”terminal
before starting. This is to prevent short circuits
during installation. (Figure 1)
2. Package Contents
3. General Cautions
1. Do not open the case. There are no
user- serviceable parts inside. If you
drop anything into the unit during
installation, consult your dealer or an
authorized Clarion service center.
2. Use a soft, dry cloth to clean the case.
Never use a rough cloth, thinner,
benzine, or alcohol etc. For tough dirt,
apply a little cold or warm water to a
soft cloth and wipe off the dirt gently.
Main unit .................................... 1
GPS antenna ............................. 1
Wiring harness ........................... 1
AV cable .................................... 1
USB extension cable ................. 1
Remote control unit ................... 1
Battery (CR2025) ....................... 1
(Installed in remote control)
2DIN trim ring ........................... 1
2DIN trim ring 200mm wide ...... 1
Back Strap ................................. 1
Flush mount bolts ..................... 4
Cap bolts ................................... 4
Rear radio stud and stopper .... 1
Cleaning cloth ........................... 1
Warranty Card ........................... 1
Owner’s manual and
Installation manual .................... 1
CONTENTS
1.
Before Starting ....................................................................55
2.
Package Contents .............................................................. 55
3
. General Cautions ................................................................ 55
4.
Cautions On Installation ..................................................... 56
5.
Installing The Main Unit ...................................................... 57
6.
Cautions On Wiring ............................................................ 59
7.
Wire Connections ...............................................................60

Table of Contents
