60 NX500/NZ500
English
Owner’s Manual
iPod
Video In
Audio/L
Audio/R
Connector Cable
4-Channel Amplifier
Subwoofer 1
Subwoofer 2
Line Out
Rear
R
Line Out
Rear
L
Line Out
Front
R
Line Out
Front
L
Purple
Red
Gray
Black
White
Red
White
Steering Wheel
Remote Control Terminal
Yellow
Monitor
Yellow
Connector
Cable
Sirius
SIRIUS CONNECT VEHICLE TUNER
Yellow
White
Red
Radio Antenna
GPS
Antenna
External
Microphone
Connection
Red
White
Gray
Black
Black
Black
Black
Black
Video Out
Video Out
Camera
HD Radio
Red
HD Radio™ Tuner Module
7. Wire Connections
Note:
•
Before installing, be sure to disconnect the negative cable of the car battery.
•
In the optional devices, the RCA cables and the Connector cables are separately-sold
items.
NX500
Refer to
page 61
iPod/iPhone
