Apex Tool Group GmbH P2398PM | 2018-12 43
Menus and Functions
3
EN
3.11.2 Saving an archive
The measurement results in the archive data can only be saved in the FastApps mode. In the mPro mode,
no archive data are recorded on the tool.
> >
Abb. 3-34: Submenu – Saving an archive
To save the archive:
1. Connect the USB stick with the tool via the Micro B USB cable.
2. Navigate to Saving an archive:
> >
3. must be pressed to start the saving process.
→ The progress bar and status bar indicate when the archive is saved.
→A .csv file is generated.
The .csv file contains a table with the following columns:
Button Description
Start the saving process.
Display of the saving progress.
The status bar indicates what percentage of the archive is already saved.
Display of the status of the saved archive.
After saving, the status bar is red or green:
• Green: The saving process has been successfully completed. There is an "OK" in
the status line.
• Red: An error occurred during the saving process. See Error messages, software
updates and data storage, Seite 52.
Column Description
Record No. Sequential number of archive entries/results
Date Date
Time Time
App Number of the Linking group (FastApp)
Step Number of the linking/batch display
Tq Torque
TqMin Low Torque
TqMax MaxTorque
