Cleco CellCore - PIN Menu

Menus and Functions
30 P2398PM | 2018-12 Apex Tool Group GmbH
3
EN
3.8.6 PIN menu
Up to three PINs for three access levels can be defined. With the access levels, different menus can be
available. If a PIN is defined, then the menus can be opened. However, changes can only be made after
entering the required PIN.
> >
Abb. 3-18: Submenu – PIN menu
If only one PIN is defined, then it applies to all the access levels. PINs for higher access levels also apply to
the lower access levels.
Example
If asked for PIN 2, both PIN 2 (2222) and PIN 3 (3333) can be entered to access a menu. However, PIN 1
(1111) is invalid.
Button Description
Access Level 1
Valid for the menu:
Access Level 2
Valid for the menus:
Access Level 3
Valid for the menus:
PIN 1 PIN 2 PIN 3
Access Level 1 XXX
Access Level 2 XX
Access Level 3 X
The following PINs are defined: PIN 1: 1111 PIN 2: 2222 PIN 3: 3333
