Clevo P375SM - Replacing the Hard Disk Drive Bay Cover

Upgrading The Computer
6 - 14 Upgrading the Hard Disk Drive(s)
6
Replacing the Hard Disk Drive Bay Cover
1. Reinsert the HDD bay cover by placing it on the bottom case assembly and then
slide it on to the case.
2. Make sure the case markers line up before sliding any further.
3. Press down on the cover as illustrated , and then slide the cover in the
direction of arrow .
4. Replace the screw at point
Figure 6 - 10
HDD Bay Cover
Replacement
1
2
3
4
3
2
1
4
