Clevo P375SM User Manual

1 - 14 Illuminated LED Keyboard - Model B
Quick Start Guide
1
Keyboard LED Controls for Model B Computers
Note that Model B computers feature a series of additional LEDs, some of which can be configured by the key-
board controls and keyboard backlight application outlined on the following pages. Note the following keyboard
LED features unique to Model B computers.
Keyboard LED Controls for Model B Computers
Fn +
Main LED Switch (Toggle all LEDs On/Off)
Figure 1 - 8
Keyboard LED Controls for Model B Computers
Fn +
Turn Volume Bar LED On/Off
• Use the Main LED switch to turn on/off all LEDs
(except Power Button)
•Use the Fn +
key combination to turn on/off the
Volume Bar LED
• Use the keyboard LED controls and backlight
application to configure colors and effects for the
Touchpad, keyboard, power button and top case
logo LEDs
• Note that the Volume Bar LED will not oscillate if
the volume level is set lower than 20%
Top Case Logo LED (Rear)
Rear Left &
Right LEDs
Power Button
LED
Touchpad LED
Keyboard
LED
Volume Bar
LED

Clevo P375SM Specifications

General

Chipset	Intel HM87
Bluetooth	Bluetooth 4.0
Card Reader	9-in-1 Card Reader (MMC/RSMMC/SD/Mini SD/SDHC/SDXC/MS/MS Pro/MS Duo)
Operating System	Windows 8.1
Processor	Intel Core i7-4930MX
Graphics	NVIDIA GeForce GTX 780M
Display	17.3" Full HD (1920x1080)
RAM	Up to 32GB DDR3
Optical Drive	DVD Super Multi Drive
Audio	HD Audio with Sound Blaster
LAN	Gigabit Ethernet
WLAN	Intel Dual Band Wireless-AC 7260
Ports	USB 3.0, USB 2.0, HDMI
Battery	8-cell
