ClimateMaster TCH072 - Page 13

THE SMART SOLUTION FOR ENERGY EFFICIENCY
Tranquility
®
Compact Belt Drive (TCH/V) Series
Rev.: July 25, 2017
13
climatemaster.com
N
A
O1
P
O2
R
L
M
K
3.64
C
Q
T
U
VS
FDGD
6.70
E
WSE
Front View
Rear Return Front Discharge
Rear Return Front Discharge
B
Top View
Top View
Right
Side
View
WSE air coil
bleed acces
Back View
Legend
BSP = Blower Service Panel
CSP = Compressor Service Panel
CAP = Control Access Panel
MSP = Motor Service Panel
UPA = Upper Pulley Access
ACP = Aquastat Controller Panel
WSE = Waterside Economizer
Rear Return Top Discharge
Rear Return Front Discharge
Notes:
1. While clear access to all removable panels may not be
required, installer should take care to comply with all building
codes and allow adequate clearance for future field service.
2. Units require 3 feet (91 cm) clearance for water connections,
WSE coil air bleed, CAP, CSP, BSP, ACP, UPA, and MSP.
3. Factory supplied controller (aquastat) is inside unit completely
wired. To field adjust temperature setting remove ACP panel and push button.
4. Internally trapped, externally vented.
5. For top discharge units, UPA in on top and BSP is on front. For front discharge
units, UPA is on front and BSP in on top. (allow 3 feet above unit for service).
BSP
Note 5
BSP
Note 5
BSP
Note 5
UPA
Note 5
UPA
Note 5
MSP
MSP
MSP
Note 2
CAP
CSP, ACP
CSP
Note 2
Note 2
Model
Overall Cabinet
Discharge Connection Duct
Flange
Water Connections Electrical Knockouts
Return Air Connections
Using Return Air Opening
A
Depth
B
Width
C
Height
D
Supply
Width
E
Supply
Depth
F
Supply
Width
G
Supply
Depth
K
Water
Inlet
L
Water
Outlet
M
Conden-
sate
N
O 1 O 2 P Q R
S
Return
Depth
T
Return
Height
U V
160-
240
in. 39.5 82.0 69.8 17.5 14.8 17.9 11.5 26.1 3.1 14.5
25.8
8.0 15.0 11.3 1.0 1.5 77.0 35.8 31.7 2.6
cm. 100.3 208.3 177.2 44.5 37.5 45.4 29.3 66.3 7.9 36.8
65.5
20.3 38.1 28.6 2.5 3.8 195.6 90.8 80.5 6.7
TCV160-240 with WaterSide Economizer
